eJet95-72V12KW Integrated High-Thrust Linear Electric Waterjet (for PWC & Marine Craft)

eJet95-72V12KW Integrated High-Thrust Linear Electric Waterjet (for PWC & Marine Craft)

The eJet95-12.0 is an advanced, high-power integrated waterjet propulsion system designed for next-generation personal watercraft and light marine applications. Featuring an innovative all-in-one linear architecture, it combines a high-efficiency permanent magnet brushless motor with a precision-engineered jet pump into a single, rugged IP68-rated unit. Capable of delivering up to 87 kgf of thrust and propelling watercraft to speeds exceeding 55 km/h, the eJet108-12.0 offers exhilarating acceleration and top-tier performance for electric jetboards, karting boats, and lightweight jet skis. Its fully-submerged motor design ensures optimal thermal management and exceptionally quiet operation, while the anodized aluminum 6061-T6 construction guarantees long-term durability in demanding saltwater environments. The eJet108-12.0 is a turnkey, high-power-density propulsion solution that simplifies installation and delivers robust, reliable electric drive on the water.

Max Speed:55 km/h
Max. Thrust:87 kgf
Max. Speed:11,300 rpm

Quantity:
Availability:





Inquire Add to Basket

System Types:
Waterjet Pump
Kv:
<100
Controller Type:
Sensorless
Maximum Voltage:
72V
Maximum Continuous Current:
< 120A

electric waterjet PWC waterjet propulsion System High-Thrust Waterjet personal watercraft motor

Features

Specification

Dyno Tested Data

Dimension

Key Features

All-in-One Linear Jet Design: Motor, controller, and jet pump are fully integrated into a compact, lightweight unit for seamless installation and minimal footprint.
High Power & Exceptional Thrust: Delivers up to 12 kW continuous power, with peak thrust reaching 87 kgf for rapid acceleration and strong bollard pull.
Wide Voltage Compatibility: Supports 60V, 72V, and 84V battery systems (14S–20S LiPo), offering flexibility for various marine and recreational applications.
IP68 Fully Submersible: Engineered for continuous underwater operation, ideal for jet-driven crafts and toys.
High-Speed Capability: Optimized for high-RPM performance, enabling craft speeds over 55 km/h.
Real-World Validated Performance: Extensive underwater testing provides verified data across the entire throttle range—thrust, efficiency, and power output are thoroughly documented.
Saltwater-Resistant Construction: Anodized aluminum housing and stainless-steel impeller ensure durability in corrosive marine environments.
Efficient Cooling & Quiet Operation: Fully submerged motor design allows for natural water cooling and reduced acoustic signature.

Parameter	Value
Model	TF108-72V12KW
Rated Voltage	72V DC (60–84V range compatible)
Rated Power	12 kW
Peak Power	18 kW
Max Thrust	850 N (≈87 kgf)
Max Speed	55 km/h
Max Motor Speed	11,300 rpm
Motor Type	Permanent Magnet Brushless DC (12N/10P)
Motor kV	130 rpm/V
Efficiency	Up to 94%
Housing Material	Anodized Aluminum 6061-T6
Waterproof Rating	IP68
Weight (Dry)	8.8 kg
Dimensions	600 × 108 × 108 mm

Motor Dyno Testing Report

No.	C_Voltage (V)	C_Current (A)	C_Input.Power (W)	M_Voltage (V)	M_Current (A)	M_Input.Power (W)	M_efficiency (%)	M_Speed (rpm)	M_Torque (N·m)	M_Output.Power (W)
0	60.110	67.340	4046.140	44.770	57.660	4009.020	94.269	6376	5.660	3779.258
1	60.020	87.470	5247.320	44.570	76.480	5190.630	94.128	6155	7.580	4885.838
2	59.910	108.790	6515.530	44.410	97.300	6435.520	93.649	5933	9.700	6026.816
3	59.850	121.260	7254.760	44.370	109.800	7157.710	93.521	5811	11.000	6693.997
4	59.760	140.330	8383.110	44.330	129.550	8259.510	92.342	5637	12.920	7626.978
5	59.690	159.820	9534.230	44.320	150.320	9372.310	90.924	5476	14.860	8521.660
6	59.620	178.600	10640.750	44.340	170.880	10443.430	89.898	5330	16.820	9388.479
7	59.540	196.670	11701.650	44.370	191.200	11464.180	88.690	5192	18.700	10167.597

Underwater test

Item	Voltage(V)	Current(A)	Input Power(W)	Revolution(RPM)	Thrust(kgf)	Throttle(%)	Kgf Per kw
1	60	2	120	1459	3.4	20	28.33
2	60	6	360	2135	7.2	30	20.00
3	60	11	660	2709	12.5	40	18.94
4	60	18	1080	3269	16.8	50	15.56
5	60	29	1740	3924	25.7	60	14.77
6	60	46	2760	4521	34.9	70	12.64
7	60	70	4200	5245	48.2	80	11.48
8	60	102	6120	5868	55.7	90	9.10
9	60	134	8040	6508	70.6	100	8.78

Item	Voltage(V)	Current(A)	Input Power(W)	Revolution(RPM)	Thrust(kgf)	Throttle(%)	Kgf Per kw
1	72	3	216	1710	4.9	20	22.69
2	72	8	576	2496	10.1	30	17.53
3	72	14	1008	3157	16.2	40	16.07
4	72	25	1800	3826	23.9	50	13.28
5	72	42	3024	4641	34.1	60	11.28
6	72	67	4824	5452	43.2	70	8.96
7	72	99	7128	6124	57.2	80	8.02
8	72	136	9792	6687	71.1	90	7.26
9	72	163	11736	7631	80.2	100	6.83

Item	Voltage(V)	Current(A)	Input Power(W)	Revolution(RPM)	Thrust(kgf)	Throttle(%)	Kgf Per kw
1	84	3	252	1875	6.1	20	24.21
2	84	8	672	2705	12.6	30	18.75
3	84	17	1428	3551	21.5	40	15.06
4	84	32	2688	4389	32.6	50	12.13
5	84	53	4452	5237	45.2	60	10.15
6	84	85	7140	6185	63.4	70	8.88
7	84	121	10164	7008	75.4	80	7.42
8	84	151	12684	7911	81.2	90	6.40
9	84	175	14700	8824	87.1	100	5.93
