Efoil Motor Kit 48V D65L161-100kv Waterproof Motor with 4-Blade Propeller

The Quanly D65L161-100Kv Motor Kit is engineered for riders who demand maximum thrust and robust low-end power. Centered on a high-torque 100Kv waterproof brushless motor paired with a 124mm 4-blade propeller, this system delivers a proven 46.5 kgf of static thrust—ideal for heavier payloads, quick foiling starts, and superior performance in varied conditions. Its durable hard-anodized housing ensures long-term reliability in marine environments. This complete, plug-and-play kit provides eFoil builders with a trusted, high-thrust foundation for powerful and responsive rides.

Max. Static Thrust：46.5 kgf
Max. RPM：4,800
Max. Power：10 kW

Quantity:
Availability:





Inquire Add to Basket

System Types:
All
Kv:
100-150
Controller Type:
Sensorless
Maximum Voltage:
60V
Maximum Continuous Current:
< 120A

Efoil Motor Kit Waterproof Motor propulsion System 4-Blade Propeller thruster

Features

Specification

Dyno Tested Data

Dimension

Key Features

High-Thrust Performance: Optimized for maximum static thrust, delivering up to 46.5 kgf (102 lbs) to get your foil up and planing efficiently.
Precision 100Kv Motor: Provides excellent low-end torque and power delivery, ideal for heavier riders or foils requiring strong initial acceleration.
Integrated 4-Blade Propeller: The 124mm diameter, 4-blade design offers a superb balance of thrust, efficiency, and smooth, quiet operation underwater.
Rugged & Protected: Features a hard-anodized aluminum housing and comes with an optional 144mm propeller guard (sold separately) for ultimate durability.
Plug-and-Play Kit: A complete system including motor and matched propeller, designed for straightforward integration into various eFoil designs.

Parameter	Value
Model	D65L161-100Kv with 4-Blade Prop
Motor Type	Permanent Magnet Brushless DC (18N/6P)
Speed Constant (Kv)	100 RPM/V
Torque Constant (Kt)	0.06678 N·m/A
Recommended Voltage	48V DC (Compatible: 25.2-84V / 6S-20S)
Continuous Current	80A
Peak Current	200A
Max. Power	6 kW (Continuous) / 10 kW (Peak @ Max Voltage)
Max. Static Thrust	46.5 kgf (Verified: 45.6 kgf @ 48V, 114A)
Max. RPM	4,800 (Recommended) / 16,380 (Max)
Propeller	4-Blade, 124mm Diameter
Motor Weight	3.0 kg
Total Kit Weight	5.2 kg
Efficiency	>80% (Up to 91% max)
Protection Level	IP68

Underwater Performance Test: Full Load at Various Voltages

Test Unit: D65L161-100Kv Motor Kit

Item	Voltage (V)	Current (A)	Input Power (W)	Speed (RPM)	Thrust (kgf)	Throttle (%)	Thrust-to-Power (kgf/kW)
1	30	64	1,920	2,286	27.8	100	14.48
2	36	81	2,916	2,588	34.9	100	11.97
3	42	98	4,116	2,948	39.5	100	9.60
4	48	114	5,472	3,186	45.6	100	8.33

Underwater Performance Test: Full Throttle Range at 48V

Test Unit: D65L161-100Kv Motor Kit

Item	Voltage (V)	Current (A)	Input Power (W)	Speed (RPM)	Thrust (kgf)	Throttle (%)	Thrust-to-Power (kgf/kW)
1	48	4	192	1,174	5.9	30	30.73
2	48	10	480	1,420	10.8	40	22.50
3	48	20	960	1,798	16.2	50	16.88
4	48	35	1,680	2,154	24.1	60	14.35
5	48	49	2,352	2,368	29.8	70	12.67
6	48	69	3,312	2,620	35.6	80	10.75
7	48	88	4,224	2,880	39.1	90	9.26
8	48	114	5,472	3,186	45.6	100	8.33

Notes:

All test data above corresponds to the D65L161-100Kv motor kit paired with the 124mm four-blade propeller.
Key Performance Verification: At the rated 48V under full throttle (100%), the system draws 5.47 kW of input power and produces a measured static thrust of 45.6 kgf, which matches the product description of "Thrust: 45.6 Kg at 114A."
Thrust-to-Power Trend: The thrust-to-power ratio (kgf/kW) decreases as throttle and power increase, which is consistent with the general characteristic of propeller-based propulsion systems being more efficient at lower loads.
The provided test data does not include underwater performance results for the D65L161-120Kv model.
